| Make | Harrington - Two 1T Hoists driven by shared trolley motor | Harrington - Two 1T Hoists driven by shared trolley motor |
| Capacity | 2 Ton (2 x 1 Ton) | 1.814 t |
| Capacity (Bridge) | 2 Tons | |
| Capacity (Main Hoist) | 1 Ton | |
| Capacity (Aux Hoist) | 1 Ton | |
| Span | 34' 0" | 10.4 m |
| Available Lift | 20' | |
| Crane Headroom | 20" | |
| Wheelbase | 54" | |
| Overall End Truck Length | 66" | |
| Year | 2012 | 2012 |
| Control | Pendant (has switch for controlling hoists individually up/down) | Pendant (has switch for controlling hoists individually up/down) |
| Electrical | 460/3/60 | 460/3/60 |
| Status | Taken down | Taken down |
| Bridge Speed | ~ 65 FPM, VFD | ~ 65 FPM, VFD |
| Bridge Power | 0.5 HP x 2 | 0.5 HP x 2 |
| Trolley Speed | ~ 40 FPM | ~ 40 FPM |
| Trolley Power | 0.5 HP | 0.5 HP |
| Hoist Speed | 14 FPM | 14 FPM |
| Hoist Power | 1.2 HP | 1.2 HP |
| Aux Hoist Speed | 14 FPM | 14 FPM |
| Aux Hoist Power | 1.2 HP | 1.2 HP |
| Other | Includes spreader beam that hangs from both hoists | Includes spreader beam that hangs from both hoists |
Runway systems may be available. Please discuss requirements with a salesperson.
This crane is taken down and stored in Benton Harbor MI.
Loading is included in the price.
Highland Machinery & Crane makes all attempts to measure specs/dimensions as accurately as possible.
All critical dimensions are to be confirmed by customer.
