| Make | Harrington Hoists on Demag Bridge | Harrington Hoists on Demag Bridge |
| Capacity | 5/5 Ton | 4.536 t |
| Capacity (Bridge) | 5 Ton | |
| Capacity (Main Hoist) | 5 Ton | |
| Capacity (Aux Hoist) | 5 Ton | |
| Span | 60' 0" | 18.3 m |
| Available Lift | 23' | |
| Class | C | C |
| Crane Headroom | 31" | |
| Wheelbase | 98" | |
| Overall End Truck Length | 115" | |
| Year | 2010 hoists on older bridge | 2010 hoists on older bridge |
| S/N | 066675/001 | 066675/001 |
| Control | Radio w/ backup pendant | Radio w/ backup pendant |
| Electrical | 460/3/60 | 460/3/60 |
| Status | Taken down | Taken down |
| Bridge Speed | ~ 80 / 20 FPM | ~ 80 / 20 FPM |
| Bridge Power | 2 / 0.5 HP x 2 | 2 / 0.5 HP x 2 |
| Trolley Speed | 80 / 20 FPM | 80 / 20 FPM |
| Trolley Power | 0.5 / 0.1 HP | 0.5 / 0.1 HP |
| Hoist Speed | 16 / 5 FPM | 16 / 5 FPM |
| Hoist Power | 8 / 2.7 HP | 8 / 2.7 HP |
| Aux Trolley Speed | 80 / 20 FPM | 80 / 20 FPM |
| Aux Trolley Power | 0.5 / 0.1 HP | 0.5 / 0.1 HP |
| Aux Hoist Speed | 16 / 5 FPM | 16 / 5 FPM |
| Aux Hoist Power | 8 / 2.7 HP | 8 / 2.7 HP |
Runway systems may be available. Please discuss requirements with a salesperson.
This crane is taken down and stored in Benton Harbor MI.
Loading is included in the price.
Highland Machinery & Crane makes all attempts to measure specs/dimensions as accurately as possible.
All critical dimensions are to be confirmed by customer.
